Casing and Tubing
We supply and export Casing and Tubing Pipes worldwide. Our OCTG Casing and Tubing pipes are manufactured according to API 5CT standards. We have five types of casing strings "surface casing", "production casing", "casing liner", "intermediate casing", and "conductor casing". Casing and Tubing pipes are essential tools for oil exploration. These are available in various sizes and specifications as per customer requirements.
contact us to get a quote today!
Product Detail
| OCTG Tubing size | 1.9"~ 4 1/2" |
|---|---|
| Material Grade | H40, J55, K55, N80,N80Q, L80, C90, C95, T95, P110, Q125,SS95,SS110, 9%CR, 13%CR Special material L80 13Cr Tubing is available. |
| OCTG Tubing Threads | - NUE (Non-upset End), also can be called 10Rd; - EUE (External-upset-end), can be called 8Rd; |
Note: All the material is procured from API approved mills.
| Tubing Size | Nominal Weight lb/ft | Outside Diameter | Wall Thickness | Type of End Finish | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Non-upset | External-upset | in | mm | in | mm | J55 | L80-1 | N80 | C90 | T95 | P110 | |
| 1.900" | 2.40 | - | 1.900 | 48.26 | 0.125 | 3.18 | PI | - | - | - | - | - |
| 2.75 | 2.90 | 1.900 | 48.26 | 0.145 | 3.68 | PNUI | PNUI | PNUI | PNUI | PNUI | - | |
| 3.65 | - | 1.900 | 48.26 | 0.200 | 5.08 | PU | PU | PU | PU | PU | PU | |
| 2 3/8" | 4.00 | - | 2.375 | 60.32 | 0.167 | 4.24 | PN | PN | PN | PN | PN | - |
| 4.00 | 4.70 | 2.375 | 60.32 | 0.190 | 4.83 | PNU | PNU | PNU | PNU | PNU | - | |
| 5.80 | 5.95 | 2.375 | 60.32 | 0.254 | 6.45 | - | PNU | PNU | PNU | PNU | PNU | |
| 6.60 | - | 2.375 | 60.32 | 0.259 | 7.49 | - | - | P | P | P | PNU | |
| 7.35 | 7.45 | 2.375 | 60.32 | 0.336 | 8.53 | - | PU | - | PU | PU | - | |
| 2 7/8" | 6.40 | 6.50 | 2.875 | 73.02 | 0.217 | 5.51 | PNU | PNU | PNU | PNU | PNU | - |
| 7.80 | 7.90 | 2.875 | 73.02 | 0.276 | 7.01 | - | PNU | PNU | PNU | PNU | PNU | |
| 8.60 | 8.70 | 2.875 | 73.02 | 0.308 | 7.82 | - | PNU | PNU | PNU | PNU | PNU | |
| 9.35 | 9.45 | 2.875 | 73.02 | 0.340 | 8.64 | - | PU | - | PU | PU | PNU | |
| 10.50 | - | 2.875 | 73.02 | 0.392 | 9.96 | - | P | - | P | P | - | |
| 11.50 | - | 2.875 | 73.02 | 0.440 | 11.18 | - | P | - | P | P | - | |
| 3 1/2" | 7.70 | - | 3.500 | 88.90 | 0.216 | 5.49 | PN | PN | PN | PN | PN | - |
| 9.20 | 9.30 | 3.500 | 88.90 | 0.254 | 6.54 | PNU | PNU | PNU | PNU | PNU | - | |
| 10.20 | - | 3.500 | 88.90 | 0.289 | 7.34 | PN | PN | PN | PN | PN | PNU | |
| 12.70 | 12.95 | 3.500 | 88.90 | 0.375 | 9.52 | - | PNU | PNU | PNU | PNU | - | |
| 14.30 | - | 3.500 | 88.90 | 0.430 | 10.92 | - | P | - | P | P | PNU | |
| 15.50 | - | 3.500 | 88.90 | 0.476 | 12.00 | - | P | - | P | P | - | |
| 17.00 | - | 3.500 | 88.90 | 0.530 | 13.46 | - | P | - | P | P | - | |
| 4" | 9.50 | - | 4.000 | 101.60 | 0.226 | 5.74 | PN | PN | PN | PN | PN | - |
| 10.70 | - | 4.000 | 101.60 | 0.262 | 6.65 | PU | PU | PU | PU | PU | - | |
| 4 1/2" | 12.60 | 12.75 | 4.500 | 114.30 | 0.271 | 6.88 | PNU | PNU | PNU | PNU | PNU | - |
| 15.20 | - | 4.500 | 114.30 | 0.380 | 8.56 | - | P | - | P | P | - | |
| 17.00 | - | 4.500 | 114.30 | 0.380 | 9.65 | - | P | - | P | P | - | |
| 18.90 | - | 4.500 | 114.30 | 0.430 | 10.92 | - | P | - | P | P | - | |
| 21.50 | - | 4.500 | 114.30 | 0.500 | 12.70 | - | P | - | P | P | - | |
| 23.70 | - | 4.500 | 114.30 | 0.560 | 14.22 | - | P | - | P | P | - | |
| 26.10 | - | 4.500 | 114.30 | 0.630 | 16.00 | - | P | - | P | P | - | |
Product Detail
| Size | 4 1/2 inch to 20 inch |
|---|---|
| Material Grade | H40, J55, K55, N80, N80Q, L80, C90, C95, T95, P110, Q125, SS95, SS110, 9%CR, 13%CR Special for L80 13Cr |
| OCTG Casing Threads | - BTC (Buttress Thread Casing) - LTC (Long Round Thread Casing) - STC (Short Round Thread Casing) |
| Casing Size | Nominal Weight lb/ft | Outside Diameter | Wall Thickness | Type of End Finish | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | in | mm | J55 K55 | L80-1 | N80 | C90 | C95 | T95 | P110 | M65 | ||
| 4 1/2" | 9.50 | 4.500 | 114.30 | 0.205 | 5.21 | PS | - | - | - | - | - | - | - |
| 10.50 | 4.500 | 114.30 | 0.224 | 5.69 | PSB | - | - | - | - | - | - | - | |
| 11.60 | 4.500 | 114.30 | 0.250 | 6.35 | PSLB | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 13.50 | 4.500 | 114.30 | 0.290 | 7.37 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 15.10 | 4.500 | 114.30 | 0.337 | 8.56 | - | - | - | - | - | - | PLB | - | |
| 5" | 11.50 | 5.000 | 127.00 | 0.220 | 5.59 | PS | - | - | - | - | - | - | - |
| 13.00 | 5.000 | 127.00 | 0.253 | 7.52 | PSLB | - | - | - | - | - | - | - | |
| 15.00 | 5.000 | 127.00 | 0.296 | 9.19 | PSLB | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 18.00 | 5.000 | 127.00 | 0.362 | 9.19 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 21.40 | 5.000 | 127.00 | 0.437 | 11.10 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 23.20 | 5.000 | 127.00 | 0.478 | 12.14 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 24.10 | 5.000 | 127.00 | 0.500 | 12.70 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 5 1/2" | 14.00 | 5.500 | 139.70 | 0.244 | 6.20 | PS | - | - | - | - | - | - | - |
| 15.50 | 5.500 | 139.70 | 0.275 | 6.98 | PSLB | - | - | - | - | - | - | - | |
| 17.00 | 5.500 | 139.70 | 0.304 | 7.72 | PSLB | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 20.00 | 5.500 | 139.70 | 0.361 | 9.17 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 23.00 | 5.500 | 139.70 | 0.415 | 10.54 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 26.80 | 5.500 | 139.70 | 0.500 | 12.70 | - | - | - | P | - | P | P | P | |
| 29.70 | 5.500 | 139.70 | 0.562 | 14.27 | - | - | - | P | - | P | P | P | |
| 32.60 | 5.500 | 139.70 | 0. | 15.88 | - | - | - | P | - | P | P | P | |
| 35.30 | 5.500 | 139.70 | 0.687 | 17.45 | - | - | - | P | - | P | P | P | |
| 38.00 | 5.500 | 139.70 | 0.750 | 19.05 | - | - | - | P | - | P | P | P | |
| 40.50 | 5.500 | 139.70 | 0.812 | 20.62 | - | - | - | P | - | P | P | P | |
| 43.10 | 5.500 | 139.70 | 0.875 | 22.22 | - | - | - | P | - | P | P | P | |
| 7" | 20.00 | 7.000 | 177.80 | 0.272 | 6.91 | PS | - | - | - | - | - | - | PS |
| 23.00 | 7.000 | 177.80 | 0.317 | 8.05 | PSLB | PLB | PLB | PLB | PLB | - | - | PLB | |
| 26.00 | 7.000 | 177.80 | 0.362 | 9.19 | PSLB | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 29.00 | 7.000 | 177.80 | 0.408 | 10.36 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 32.00 | 7.000 | 177.80 | 0.453 | 11.51 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 35.00 | 7.000 | 177.80 | 0.498 | 12.65 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 38.00 | 7.000 | 177.80 | 0.540 | 13.72 | - | PLB | PLB | PLB | PLB | PLB | PLB | PLB | |
| 9 5/8" | 32.30 | 9.625 | 244.48 | 0.312 | 7.92 | - | - | - | - | - | - | - | - |
| 36.00 | 9.625 | 244.48 | 0.352 | 8.94 | PSLB | - | - | - | - | - | - | PSLB | |
| 40.00 | 9.625 | 244.48 | 0.395 | 8.94 | PSLB | PLB | PLB | PLB | PLB | PLB | - | PSLB | |
| 43.50 | 9.625 | 244.48 | 0.435 | 11.05 | - | PLB | PLB | PLB | PLB | PLB | PLB | - | |
| 47.00 | 9.625 | 244.48 | 0.472 | 11.99 | - | PLB | PLB | PLB | PLB | PLB | PLB | - | |
| 53.50 | 9.625 | 244.48 | 0.545 | 13.84 | - | PLB | PLB | PLB | PLB | PLB | PLB | - | |
| 58.40 | 9.625 | 244.48 | 0.595 | 15.11 | - | PLB | PLB | PLB | PLB | PLB | PLB | - | |
| 59.40 | 9.625 | 244.48 | 0.609 | 15.47 | - | - | - | P | - | P | - | - | |
| 64.90 | 9.625 | 244.48 | 0.672 | 17.07 | - | - | - | P | - | P | - | - | |
| 70.30 | 9.625 | 244.48 | 0.734 | 18.64 | - | - | - | P | - | P | - | - | |
| 75.60 | 9.625 | 244.48 | 0.797 | 20.24 | - | - | - | P | - | P | - | - | |
| 13 3/8" | 48.00 | 13.375 | 339.72 | 0.330 | 8.38 | - | - | - | - | - | - | - | - |
| 54.50 | 13.375 | 339.72 | 0.380 | 9.65 | PSB | - | - | - | - | - | - | PSB | |
| 61.00 | 13.375 | 339.72 | 0.430 | 10.92 | PSB | - | - | - | - | - | - | PSB | |
| 68.00 | 13.375 | 339.72 | 0.480 | 12.19 | PSB | PSB | PSB | PSB | PSB | PSB | PSB | PSB | |
| 72.00 | 13.375 | 339.72 | 0.514 | 13.06 | - | PSB | PSB | PSB | PSB | PSB | PSB | - | |
