Casing Pup joints

We are a Supplier and Exporter of Casing Pup joints in UAE. It's mainly used to adjust the height of the casing strings. Our casing pup joints are made under the API 5CT specifications. These product features are high corrosion resistance or long running life.

We supply casing pup joints in all sizes, grades, and thread profiles to meet custom requirements. All our products have passed the ISO certification and API certifications. Our products are tested numerous times under technical guidance and are made from the best quality material. It is also used to balance the depth of down-hole tools.

TECHNICAL SPECIFICATIONS:

Grades: H40, J55, K55, N80, L80 T95, C110, P110, and Q125.
Thread types: LTC, STC, BTC, Semi Premium, and Premium.
Outer Diameter 4 ½” – 13 3/8”
Wall thickness: 6.35mm to 16.13mm.
Length: 2, 3, 4, 6, 8, 10, and 12 ft. Standards (Length up to 20" available upon request).
Customized lengths and diameters are available upon request.

Nominal Size	Outer Diameter		Weight T&C	Wall Thickness		Type of Ends
	Outer Diameter		Weight T&C	Wall Thickness		Steel Grade
	in.	mm	lb/ft	In.	mm	J55 K55	L80 C95	N80-1 N80-Q	C95 T95	P110	Q125
4 1/2"	4.5	114.3	11.6	0.25	6.35	SLB	LB	LB	LB	LB	-
			13.5	0.29	7.37	-	LB	LB	LB	LB	-
			15.1	0.337	8.56	-	-	-	-	LB	LB
5"	5	127	15	0.296	7.52	SLB	LB	LB	LB	LB	-
			18	0.362	9.19	-	LB	LB	LB	LB	LB
			21.4	0.437	11.1	-	LB	LB	LB	LB	LB
5 1/2"	5.5	139.7	17	0.304	7.72	SLB	LB	LB	LB	LB	-
			20	0.361	9.17	-	LB	LB	LB	LB	-
			23	0.415	10.54	-	LB	LB	LB	LB	LB
6 5/8"	6.625	168.28	24	0.352	8.94	SLB	LB	LB	LB	LB	-
			28	0.417	10.59	-	LB	LB	LB	LB	-
			32	0.475	12.06	-	LB	LB	LB	LB	LB
7"	7	177.8	23	0.317	8.05	SLB	LB	LB	LB	-	-
			26	0.362	9.19	SLB	LB	LB	LB	LB	-
			29	0.408	10.36	-	LB	LB	LB	LB	-
			32	0.453	11.51	-	LB	LB	LB	LB	-
7 5/8"	7.625	193.68	26.4	0.328	8.33	SLB	LB	LB	LB	LB	-
			29.7	0.375	9.53	-	LB	LB	LB	LB	-
			33.7	0.43	10.92	-	LB	LB	LB	LB	-
			39	0.5	12.7	-	LB	LB	LB	LB	LB
8 5/8"	8.625	219.08	36	0.4	10.16	SLB	LB	LB	LB	SLB	-
			40	0.45	11.43	-	LB	LB	LB	LB	-
			44	0.5	12.7	-	LB	LB	LB	LB	LB
9 5/8"	9.625	244.48	40	0.395	10.03	SLB	LB	LB	LB	-	-
			43.5	0.435	11.05	-	LB	LB	LB	LB	-
			47	0.472	11.99	-	LB	LB	LB	LB	LB
10 3/4"	10.75	273.05	51	0.45	11.43	SB	SB	SB	SB	SB	-
10 3/4"	10.75	273.05	55.5	0.495	12.57	-	SB	SB	SB	SB	-
11 3/4"	11.75	298.45	60	0.489	12.42	SB	SB	SB	SB	SB	SB
13 3/8"	13.375	339.73	68	0.48	12.19	SB	SB	SB	SB	SB	-
13 3/8"	13.375	339.73	72	0.514	13.06	-	SB	SB	SB	SB	SB
16"	16	406.4	75	0.438	11.13	SB	-	-	-	-	-
16"	16	406.4	84	0.4958	12.57	Sb	-	-	-	-	-
18 5/8"	18.625	473.08	87.5	0.435	11.05	SB	-	-	-	-	-
20"	20	508	94	0.438	11.13	SLB	-	-	-	-	-
			106.5	0.5	12.7	SLB	-	-	-	-	-
			133	0.635	16.13	SLB	-	-	-	-	-
