Pup Joint
DIC is an Exporter of Pup Joints. These are used to adjust the depth of downhole tools. All our pup joints are manufactured as per API 5CT requirements. Due to their shorter length, they are typically easier to handle. All hard banding and coating options are available as per required. Premium Pup Joints are also available with premium connections in API or exotic alloy grades.
If you have any query, Contact us Or, Request a quote Now!!
Product Specifications:
- Standard: API 5CT 10th Edition
- Specification: From 0.75” to 20”
- Grade: H40, J55, K55, N80, L80, C90, T95, P110, C110, Q125
- Connection: EU, NU, SC, LC, BC, and premium thread, Pin * Pin, Box*Pin.
Note: All the material is procured from API approved mills.
Tubing Pup Joint
| Outside Diameter | 0.75 to 4.5 inches nominal size OD |
|---|---|
| Weight | Standard or Heavy Wall |
| Lengths | 2,3,4,6,8,10 12 ft (with other lengths available upon request) |
| Grades | J-55, N-80, N-80Q & T, L-80, P-110, H40, C90 |
| Connections | EUE, NUE, Buttress, and Premium Connections of leading manufacturers are available. |
| (O D) | Nominal Mass (lb/ft) Threaded and Coupled |
O.D. | W.T. | Nominal Weight (kg/m) Threaded and Coupled | Type of Pipe Ends Grades | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| In . | mm | In . | mm | |||||||||||
| NUE | EUE | NUE | EUE | J - 55 | L - 80 | N - 80 | C - 90 | T - 95 | P - 110 | |||||
| 2 3/8 " | 4.00 | -- | 2.375 | 60.32 | 0.169 | 4.24 | 5.95 | -- | PN | PN | PN | PN | PN | PNU |
| 4.60 | 4.70 | 2.375 | 60.32 | 0.190 | 4.83 | 6.85 | 6.99 | PNU | PNU | PNU | PNU | PNU | PNU | |
| 5.80 | 5.95 | 2.375 | 60.32 | 0.254 | 6.45 | 8.63 | 8.85 | -- | PNU | PNU | PNU | PNU | -- | |
| 6.60 | -- | 2.375 | 60.32 | 0.295 | 7.49 | 9.82 | -- | -- | P | -- | P | P | -- | |
| 7.35 | 7.45 | 2.375 | 60.32 | 0.336 | 8.53 | 10.94 | 11.09 | -- | PU | -- | PU | PU | PNU | |
| 2 7/8 " | 6.40 | 6.50 | 2.375 | 73.02 | 0.217 | 5.51 | 9.52 | 9.67 | PUN | PNU | PNU | PNU | PNU | PNU |
| 7.80 | 7.90 | 2.375 | 73.02 | 0.276 | 7.01 | 11.61 | 11.76 | -- | PNU | PNU | PNU | PNU | PNU | |
| 8.60 | 8.70 | 2.375 | 73.02 | 0.308 | 7.82 | 12.80 | 12.95 | -- | PNU | PNU | PNU | PNU | -- | |
| 9.35 | 9.45 | 2.375 | 73.02 | 0.340 | 8.64 | 13.91 | 14.06 | -- | PU | -- | PU | PU | -- | |
| 10.50 | -- | 2.375 | 73.02 | 0.392 | 9.96 | 15.63 | -- | -- | P | -- | P | P | -- | |
| 11.50 | -- | 2.375 | 73.02 | 0.440 | 11.18 | 17.11 | -- | -- | P | -- | P | P | -- | |
| 3 1/2 " | 7.70 | -- | 3.500 | 88.90 | 0.216 | 5.49 | 11.46 | -- | PN | PN | PN | PN | PN | PNU |
| 9.20 | 9.30 | 3.500 | 88.90 | 0.254 | 6.45 | 13.69 | 13.84 | PNU | PNU | PNU | PNU | PNU | -- | |
| 10.20 | -- | 3.500 | 88.90 | 0.289 | 7.34 | 15.18 | -- | PN | PN | PN | PN | PN | PNU | |
| 12.70 | 12.95 | 3.500 | 88.90 | 0.375 | 9.52 | 18.90 | 19.27 | -- | PNU | PNU | PNU | PNU | -- | |
| 14.30 | -- | 3.500 | 88.90 | 0.430 | 10.92 | 21.28 | -- | -- | P | -- | P | P | -- | |
| 15.50 | -- | 3.500 | 88.90 | 0.476 | 12.09 | 23.07 | -- | -- | P | -- | P | P | -- | |
| 17.00 | -- | 3.500 | 88.90 | 0.530 | 13.46 | 25.30 | -- | -- | P | -- | P | P | -- | |
| 4" | 9.50 | -- | 4.000 | 101.60 | 0.226 | 5.74 | 14.14 | -- | PN | PN | PN | PN | PN | -- |
| 10.70 | 11.00 | 4.000 | 101.60 | 0.262 | 6.65 | -- | 16.37 | PU | PU | PU | PU | PU | -- | |
| 13.20 | -- | 4.000 | 101.60 | 0.330 | 8.38 | 19.64 | -- | -- | P | -- | P | P | -- | |
| 16.10 | -- | 4.000 | 101.60 | 0.415 | 10.54 | 23.96 | -- | -- | P | -- | P | P | -- | |
| 18.90 | -- | 4.000 | 101.60 | 0.500 | 12.70 | 28.13 | -- | -- | P | -- | P | P | -- | |
| 22.20 | -- | 4.000 | 101.60 | 0.610 | 15.49 | 33.04 | -- | -- | P | -- | P | P | -- | |
| 4 1/2 " | 12.60 | 12.75 | 4.500 | 114.30 | 0.271 | 6.88 | 18.75 | 18.97 | PUN | PNU | PNU | PNU | PNU | -- |
| 15.20 | -- | 4.500 | 114.30 | 0.337 | 8.56 | 22.62 | -- | -- | P | -- | P | P | -- | |
| 17.00 | -- | 4.500 | 114.30 | 0.380 | 9.65 | 25.30 | -- | -- | P | -- | P | P | -- | |
| 18.90 | -- | 4.500 | 114.30 | 0.430 | 10.92 | 28.13 | -- | -- | P | -- | P | P | -- | |
| 21.50 | -- | 4.500 | 114.30 | 0.500 | 12.70 | 32.00 | -- | -- | P | -- | P | P | -- | |
| 23.70 | -- | 4.500 | 114.30 | 0.560 | 14.22 | 35.27 | -- | -- | P | -- | P | P | -- | |
| 26.10 | -- | 4.500 | 114.30 | 0.630 | 16.00 | 38.84 | -- | -- | P | -- | P | P | -- | |
Casing Pup Joint
| Outside Diameter | 0.75 to 4.5 inches nominal size OD |
|---|---|
| Weight | Standard or Heavy Wall |
| Lengths | 2,3,4,6,8,10 12 ft (with other lengths available upon request) |
| Grades | J-55, N-80, N-80Q & T, L-80, P-110, H40, C90, Q125 |
| Connections | EUE, NUE, Buttress, and Premium Connections of leading manufacturers are available. |
| (O D) | Nominal Weight | O.D. | W.T. | Nominal Linear Mass T&C | Plain-End | Mass Gain or Loss Due To End Finishing (kg) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Round Thread | Buttress Thread | ||||||||||
| (lb/ft) | in | mm | in | mm | Kg/m | kg/m | STC | LTC | Normal | SCC | |
| 4 1/2" | 9.50 | 4.500 | 114.30 | 0.205 | 5.21 | 14.38 | 14.02 | 1.91 | ‐‐ | ‐‐ | ‐‐ |
| 10.50 | 4.500 | 114.30 | 0.224 | 5.69 | 15.73 | 15.24 | 1.72 | ‐‐ | 2.27 | 1.16 | |
| 11.60 | 4.500 | 114.30 | 0.250 | 6.35 | 17.38 | 16.91 | 1.54 | 1.72 | 2.09 | 0.98 | |
| 13.50 | 4.500 | 114.30 | 0.290 | 7.37 | 19.87 | 19.44 | ‐‐ | 1.45 | 1.81 | 0.71 | |
| 15.10 | 4.500 | 114.30 | 0.337 | 8.56 | 22.69 | 22.32 | ‐‐ | 1.27 | 1.45 | 0.34 | |
| 5" | 11.50 | 5.000 | 127.00 | 0.220 | 5.59 | 17.19 | 16.74 | 2.45 | ‐‐ | ‐‐ | ‐‐ |
| 13.00 | 5.000 | 127.00 | 0.253 | 6.43 | 19.69 | 19.12 | 2.18 | 2.63 | 2.99 | 1.10 | |
| 15.00 | 5.000 | 127.00 | 0.296 | 7.52 | 22.69 | 22.16 | 1.91 | 2.36 | 2.63 | 0.73 | |
| 18.00 | 5.000 | 127.00 | 0.362 | 9.19 | 27.19 | 26.70 | ‐‐ | 1.91 | 2.00 | 0.10 | |
| 21.40 | 5.000 | 127.00 | 0.437 | 11.10 | 32.13 | 31.73 | ‐‐ | 1.34 | 1.12 | -0.78 | |
| 23.20 | 5.000 | 127.00 | 0.478 | 12.14 | 34.76 | 34.39 | ‐‐ | 1.04 | 0.93 | -0.95 | |
| 24.10 | 5.000 | 127.00 | 0.500 | 12.70 | 36.15 | 35.80 | ‐‐ | 0.88 | 0.56 | -1.33 | |
| 5 1/2" | 14.00 | 5.500 | 139.70 | 0.244 | 6.20 | 20.91 | 20.41 | 2.45 | ‐‐ | ‐‐ | ‐‐ |
| 15.50 | 5.500 | 139.70 | 0.275 | 6.98 | 23.48 | 22.85 | 2.18 | 2.63 | 2.90 | 0.95 | |
| 17.00 | 5.500 | 139.70 | 0.304 | 7.72 | 25.72 | 25.13 | 2.00 | 2.45 | 2.63 | 0.68 | |
| 20.00 | 5.500 | 139.70 | 0.361 | 9.17 | 30.05 | 29.52 | ‐‐ | 2.00 | 2.09 | 0.14 | |
| 23.00 | 5.500 | 139.70 | 0.415 | 10.54 | 34.05 | 33.57 | ‐‐ | 1.45 | 1.54 | -0.41 | |
| 26.80 | 5.500 | 139.70 | 0.500 | 12.70 | 40.15 | 39.78 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 29.70 | 5.500 | 139.70 | 0.562 | 14.27 | 44.47 | 44.14 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 32.60 | 5.500 | 139.70 | 0.625 | 15.88 | 48.74 | 48.49 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 35.30 | 5.500 | 139.70 | 0.687 | 17.45 | 52.80 | 52.61 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 38.00 | 5.500 | 139.70 | 0.750 | 19.05 | 56.82 | 56.68 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 40.50 | 5.500 | 139.70 | 0.812 | 20.62 | 60.64 | 60.55 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 43.10 | 5.500 | 139.70 | 0.875 | 22.22 | 64.41 | 64.38 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 6 5/8" | 20.00 | 6.625 | 168.28 | 0.288 | 7.32 | 29.76 | 29.06 | 4.99 | 6.17 | 6.53 | 1.08 |
| 24.00 | 6.625 | 168.28 | 0.352 | 8.94 | 35.72 | 35.13 | 4.35 | 5.44 | 5.73 | 0.26 | |
| 28.00 | 6.625 | 168.28 | 0.417 | 10.59 | 41.67 | 41.18 | ‐‐ | 4.63 | 4.81 | -0.64 | |
| 32.00 | 6.625 | 168.28 | 0.475 | 12.06 | 47.62 | 46.46 | ‐‐ | 3.99 | 4.08 | -1.37 | |
| 7" | 17.00 | 7.000 | 177.80 | 0.231 | 5.87 | 25.60 | 24.89 | 4.54 | ‐‐ | ‐‐ | ‐‐ |
| 20.00 | 7.000 | 177.80 | 0.272 | 6.91 | 29.91 | 29.12 | 4.26 | ‐‐ | ‐‐ | ‐‐ | |
| 23.00 | 7.000 | 177.80 | 0.317 | 8.05 | 34.67 | 33.70 | 3.63 | 4.72 | 4.99 | 0.73 | |
| 26.00 | 7.000 | 177.80 | 0.362 | 9.19 | 39.14 | 38.21 | 3.63 | 4.72 | 4.99 | 0.73 | |
| 29.00 | 7.000 | 177.80 | 0.408 | 10.36 | 43.60 | 42.78 | 3.27 | 4.26 | 4.35 | 0.09 | |
| 32.00 | 7.000 | 177.80 | 0.453 | 11.51 | 47.92 | 47.20 | ‐‐ | 3.63 | 3.72 | -0.54 | |
| 35.00 | 7.000 | 177.80 | 0.498 | 12.65 | 52.09 | 51.52 | ‐‐ | 2.99 | 3.08 | -1.18 | |
| 38.00 | 7.000 | 177.80 | 0.540 | 13.72 | 56.10 | 55.52 | ‐‐ | 2.54 | 2.54 | -1.72 | |
| 42.70 | 7.000 | 177.80 | 0.625 | 15.88 | 63.84 | 63.41 | ‐‐ | 2.00 | 1.91 | -2.36 | |
| 46.40 | 7.000 | 177.80 | 0.687 | 17.45 | 69.35 | 69.41 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 50.10 | 7.000 | 177.80 | 0.750 | 19.0 | 74.85 | 74.58 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 53.60 | 7.000 | 177.80 | 0.812 | 20.62 | 80.21 | 79.93 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 57.10 | 7.000 | 177.80 | 0.875 | 22.22 | 85.42 | 85.25 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| (O D) | Nominal Weight | O.D. | W.T. | Nominal Linear Mass T&C | Plain-End | Mass Gain or Loss Due To End Finishing (kg) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Round Thread | Buttress Thread | (lb/ft) | in | mm | in | mm | Kg/m | kg/m | Short | Long | RC | SCC |
| 7 5/8" | 24.00 | 7.625 | 193.68 | 0.300 | 7.62 | 35.72 | 34.96 | 7.11 | ‐‐ | ‐‐ | ‐‐ |
| 26.40 | 7.625 | 193.68 | 0.328 | 8.33 | 39.29 | 38.08 | 6.78 | 8.58 | 9.12 | 2.59 | |
| 29.70 | 7.625 | 193.68 | 0.375 | 9.52 | 44.20 | 43.24 | ‐‐ | 7.91 | 8.38 | 1.84 | |
| 33.70 | 7.625 | 193.68 | 0.430 | 10.92 | 50.15 | 49.22 | ‐‐ | 7.13 | 7.51 | 0.98 | |
| 39.00 | 7.625 | 193.68 | 0.500 | 12.70 | 58.04 | 56.68 | ‐‐ | 6.16 | 6.44 | -0.10 | |
| 42.80 | 7.625 | 193.68 | 0.562 | 14.27 | 63.69 | 63.14 | ‐‐ | 5.32 | 5.50 | -1.03 | |
| 45.30 | 7.625 | 193.68 | 0.595 | 15.11 | 67.41 | 66.54 | ‐‐ | 4.87 | 5.01 | -1.52 | |
| 47.10 | 7.625 | 193.68 | 0.625 | 15.88 | 70.09 | 69.63 | ‐‐ | 4.48 | 4.57 | -1.96 | |
| 51.20 | 7.625 | 193.68 | 0.687 | 17.45 | 76.19 | 75.84 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 55.30 | 7.625 | 193.68 | 0.750 | 19.05 | 82.30 | 82.04 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 7 3/4" | 46.10 | 7.750 | 196.85 | 0.595 | 15.11 | 68.60 | 67.72 | ‐‐ | ‐‐ | ‐‐ | ‐‐ |
| 8 5/8" | 24.00 | 8.625 | 219.08 | 0.264 | 6.71 | 35.72 | 35.14 | 10.93 | ‐‐ | ‐‐ | ‐‐ |
| 28.00 | 8.625 | 219.08 | 0.304 | 7.72 | 41.62 | 40.24 | 10.07 | ‐‐ | ‐‐ | ‐‐ | |
| 32.00 | 8.625 | 219.08 | 0.352 | 8.94 | 47.67 | 46.33 | 9.39 | 12.44 | 12.57 | 2.51 | |
| 36.00 | 8.625 | 219.08 | 0.400 | 10.16 | 53.57 | 52.35 | 8.72 | 11.60 | 11.68 | 1.62 | |
| 40.00 | 8.625 | 219.08 | 0.450 | 11.43 | 59.53 | 58.53 | ‐‐ | 10.73 | 10.77 | 0.71 | |
| 44.00 | 8.625 | 219.08 | 0.500 | 12.70 | 65.48 | 64.64 | ‐‐ | 9.88 | 9.87 | -0.20 | |
| 49.00 | 8.625 | 219.08 | 0.557 | 14.15 | 72.92 | 71.51 | ‐‐ | 8.88 | 8.85 | -1.21 | |
| 9 5/8" | 32.30 | 9.625 | 244.48 | 0.312 | 7.92 | 48.07 | 46.20 | 11.00 | ‐‐ | ‐‐ | ‐‐ |
| 36.00 | 9.625 | 244.48 | 0.352 | 8.94 | 53.57 | 51.93 | 10.36 | 14.48 | 13.87 | 2.72 | |
| 40.00 | 9.625 | 244.48 | 0.395 | 10.03 | 59.53 | 57.99 | 9.69 | 13.59 | 12.97 | 1.84 | |
| 43.50 | 9.625 | 244.48 | 0.435 | 11.05 | 64.73 | 63.61 | ‐‐ | 12.78 | 12.15 | 1.01 | |
| 47.00 | 9.625 | 244.48 | 0.472 | 11.99 | 69.94 | 68.75 | ‐‐ | 12.03 | 11.39 | 0.25 | |
| 53.50 | 9.625 | 244.48 | 0.545 | 13.84 | 79.62 | 78.72 | ‐‐ | 10.57 | 9.92 | -1.22 | |
| 58.40 | 9.625 | 244.48 | 0.595 | 15.11 | 86.91 | 85.47 | ‐‐ | 9.58 | 8.92 | -2.22 | |
| 59.40 | 9.625 | 244.48 | 0.609 | 15.47 | 88.40 | 87.37 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 64.90 | 9.625 | 244.48 | 0.672 | 17.07 | 96.58 | 95.73 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 70.30 | 9.625 | 244.48 | 0.734 | 18.64 | 104.62 | 103.82 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 75.60 | 9.625 | 244.48 | 0.797 | 20.24 | 112.51 | 111.93 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 10 3/4" | 32.75 | 10.75 | 273.05 | 0.279 | 7.09 | 48.74 | 46.50 | 13.94 | ‐‐ | ‐‐ | ‐‐ |
| 40.50 | 10.75 | 273.05 | 0.350 | 8.89 | 60.27 | 57.91 | 11.91 | ‐‐ | 15.38 | 3.03 | |
| 45.50 | 10.75 | 273.05 | 0.400 | 10.16 | 67.71 | 65.87 | 11.00 | ‐‐ | 14.21 | 1.86 | |
| 51.00 | 10.75 | 273.05 | 0.450 | 11.43 | 75.90 | 73.75 | 10.11 | ‐‐ | 13.05 | 0.70 | |
| 55.50 | 10.75 | 273.05 | 0.495 | 12.57 | 82.59 | 80.75 | 9.30 | ‐‐ | 12.25 | -0.09 | |
| 60.70 | 10.75 | 273.05 | 0.545 | 13.84 | 90.33 | 88.47 | 8.42 | ‐‐ | 11.07 | ‐‐ | |
| 65.70 | 10.75 | 273.05 | 0.595 | 15.11 | 97.77 | 96.12 | 7.54 | ‐‐ | 9.98 | ‐‐ | |
| 73.20 | 10.75 | 273.05 | 0.672 | 17.07 | 108.93 | 107.76 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 79.20 | 10.75 | 273.05 | 0.734 | 18.64 | 117.86 | 116.95 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 85.30 | 10.75 | 273.05 | 0.797 | 20.24 | 126.94 | 126.19 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 11 3/4" | 42.00 | 11.75 | 298.45 | 0.333 | 8.46 | 62.50 | 62.56 | 13.27 | ‐‐ | ‐‐ | ‐‐ |
| 47.00 | 11.75 | 298.45 | 0.375 | 9.53 | 69.94 | 67.83 | 12.42 | ‐‐ | 16.04 | ‐‐ | |
| 54.00 | 11.75 | 298.45 | 0.435 | 11.05 | 80.36 | 78.32 | 11.23 | ‐‐ | 14.50 | ‐‐ | |
| 60.00 | 11.75 | 298.45 | 0.489 | 12.42 | 89.29 | 87.61 | 10.17 | ‐‐ | 13.12 | ‐‐ | |
| 65.00 | 11.75 | 298.45 | 0.534 | 13.56 | 96.73 | 95.27 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 71.00 | 11.75 | 298.45 | 0.582 | 14.78 | 105.66 | 103.40 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 48.00 | 13.375 | 339.72 | 0.330 | 8.38 | 71.43 | 68.48 | 15.04 | ‐‐ | ‐‐ | ‐‐ | |
| 54.50 | 13.375 | 339.72 | 0.380 | 9.65 | 81.10 | 78.55 | 13.88 | ‐‐ | 17.91 | ‐‐ | |
| 61.00 | 13.375 | 339.72 | 0.430 | 10.92 | 90.78 | 88.55 | 12.74 | ‐‐ | 16.44 | ‐‐ | |
| 68.00 | 13.375 | 339.72 | 0.480 | 12.19 | 101.19 | 98.46 | 11.61 | ‐‐ | 14.97 | ‐‐ | |
| 72.00 | 13.375 | 339.72 | 0.514 | 13.06 | 107.15 | 105.21 | 10.98 | ‐‐ | 14.33 | ‐‐ | |
| 16" | 65.00 | 16.00 | 406.40 | 0.375 | 9.53 | 96.73 | 96.73 | 18.59 | ‐‐ | ‐‐ | ‐‐ |
| 75.00 | 16.00 | 406.40 | 0.438 | 11.13 | 111.61 | 108.49 | 16.66 | ‐‐ | 20.13 | ‐‐ | |
| 84.00 | 16.00 | 406.40 | 0.495 | 12.57 | 125.01 | 122.09 | 14.92 | ‐‐ | 18.11 | ‐‐ | |
| 109.00 | 16.00 | 406.40 | 0.656 | 16.66 | 162.21 | 160.13 | ‐‐ | ‐‐ | ‐‐ | ‐‐ | |
| 18 5/8" | 87.50 | 18.625 | 473.08 | 0.435 | 11.05 | 130.21 | 125.91 | 33.60 | ‐‐ | 39.25 | ‐‐ |
| 20" | 94.00 | 20.00 | 508.00 | 0.438 | 11.13 | 139.89 | 136.38 | 20.50 | 27.11 | 24.78 | ‐‐ |
| 106.50 | 20.00 | 508.00 | 0.500 | 12.70 | 158.49 | 155.13 | 18.22 | 24.27 | 22.00 | ‐‐ | |
| 133.00 | 20.00 | 508.00 | 0.635 | 16.13 | 197.93 | 195.66 | 13.03 | 17.84 | 16.02 | ‐‐ | |
